Description
| RS★R Black★iRS Black Eye |
||||||||||||
 ■Powerful low form that crawls on the ground <Development concept> Black☆i has been developed based on a completely different concept from the conventional i☆SHOCK series. Each model is initially shipped with a design that secures a minimum ground clearance of 90mm to 100mm (*1), but in terms of the amount of down, it is possible to set a down area that exceeds that of the conventional i☆SHOCK series. In addition, we have designed a super short stroke and super short case shock exclusively for Black☆i for each car model, and by adopting hard specifications along with damping force and spring rate, we suppress unnecessary movement of the car body and create a powerful impact. Achieves a down form and sharp driving performance. If the standard included spring is a straight type, the spring rate can be selected within the design range. *1: Values are based on measurement data in the specifications of the vehicle developed by RSR. (All items except shocks must be in original condition) <Important Notes> ◇The dimensions at the time of shipment from RSR will ensure a minimum ground clearance of 90 to 100 mm. (Limited to standard spring specifications) However, the values are based on the measurement data for the specifications of the vehicle developed by RSR. (All items except shocks must be in original condition) ◇If the vehicle height is changed to a height other than the factory dimensions, please be sure to comply with the "Safety Standards for Road Transport Vehicles." If the vehicle height is lowered too much, there will always be interference with the suspension arms, tires, body, etc. Any adjustments to the vehicle height or changes to spring rates other than the standard spring rate are at the user's own risk. In addition, the user is responsible for any changes in vehicle height due to age deterioration in parts other than the product itself. ◇Except for defects in the product itself, we cannot be held responsible for any troubles or malfunctions during use. ◇Since this product is intended for maximum lowdown, it does not come with a ride comfort guarantee or a one-year product warranty. <Features>
|
| Product information | |
| 【Product name】 | RS☆R Black-i RS☆R Black-i |
| [Setting car model] | Compatible model: TOYOTA PRIUS FF Compatible model: MXWH60 year : 2023/1~ ■Recommended vehicle height (maximum vehicle height) adjustment range *Grade G Fr: -50~-55mm (-40~-110mm) Rr: -50~ -55mm (-30 to -100mm) ★Minimum ground clearance of 90 to 100mm is ensured at the time of shipment (recommended specifications only) ■Spring rate (kg/mm) recommended specifications Fr: 8.00 / Rr: 7.00 Spring rate selection range Fr: 6-12K / Rr: 5-11K *You can change the selection from the above selection range rates when ordering ■Damping force adjustment Fr: ○ / Rr: ○ ■Number of adjustment stages Fr: 36 / Rr: 36 ■Overall length adjustment Fr: ○ / Rr :○ ■Front camber adjustment:○ ■Rear height adjustment: Full length type [Notes] ●Reuse of rear genuine upper mount ●Front damping force adjustment bottom dial specification ●Rear coil over specification |
Details
_installation_available: |
Yes |
