Description
Kit Contents
Reference 500 Kit Includes
REFERENCE 500 KIT
- Reference 500 Amp 56 Bit Multi-Channel Class AB DSP Amp
- Dedicated Sub-Amp w/ remote base Gain Control Knob
- Quick Sync Plug-n-Play Wiring Harness
- Vehicle Specific 8″ Subwoofer Enclosure Assembly
- Recalibration of Dash & Rear Speakers
- Vehicle-Specific Acoustic Tuning
- Front 1″ Soft Dome Tweeters
- Front 6.5″ Carbon Fiber Woofers
.Specifications
Reference 500 Kit Specifications
REFERENCE 500 MULTI-CHANNEL POWER AMPLIFIER
- GR86 Base/ BRZ Premium (2-Way)
- 180W (40W x 4 @ 4-Ohms)
- Output Power (0.03% THD)
- 52-Bit Digital Signal Processing (Class AB)
- Reverse Voltage Protection
- Under Voltage Detection to protect the vehicle battery
- Thermal Protection when exceeding 194° F
- ESD Protection (Electrostatic Discharge)
- OEM Audio + Proprietary Acoustic Tuning
- Meets all OEM Standards
- Powers and Remasters All Speakers
- Recalibration of Dash & Rear Factory Speakers
DEDICATED SUBWOOFER AMPLIFIER
- More Headroom + Low-Frequency Extension
- 250W (125 x 2 @ 4-Ohms)
- Mono (0.5% THD)
- Class D (95% efficient)
- Includes Remote Gain Control Knob for precision adjustability
QUICK SYNC WIRING HARNESS
- Maintains all factory functionality
- Constructed of genuine OEM connectors
- Fuse Holder Assembly is element-proof
- Includes heat-shrink butt-connectors
VEHICLE SPECIFIC 8″ SUBWOOFER ENCLOSURE ASSEMBLY
- Driver or Passenger side Subwoofer available.
- 8″ 4-Ohms Subwoofer
- 0.7 cu. ft. Sealed Fiberglass Enclosure
- Genuine Carbon Fiber Cone Woofer
- 100W RMS (200W Peak)
- Sensitivity 86.5dB (1 W,1M)
FRONT 1″ SOFT DOME TWEETERS
- Silk soft dome
- 4-ohms
- 50W RMS (100 Peak)
- Sensitivity 91.8 dB (1 W,1M)
- Frequency Response: 3,000-20,000 Hz
- Built-in 6db/Oct. High Pass Filter
- Neodymium Magnet Structure
- Plug-n-Play Speaker Connectors
FRONT 6.5″ WOOFER
- Carbon Fiber Cone Woofer
- 2-ohms
- 50W RMS (100 Peak)
- Sensitivity 86.5 dB (1 W,1M)
- Frequency Response: 55-14,000 Hz
- Plug-n-Play Speaker Connectors
VEHICLE SPECIFIC ACOUSTIC TUNING
- Tune Specific to GR86 Base/ BRZ Premium (2-Way) System
- Tune Specific to the GR86 Premium/ BRZ Limited (3-Way) System
